Weichai Medium Speed Unit Series 60Hz Marine Diesel Generator for Ship Power 200kVA-1500kVA Silent Diesel Generator

NO. GF-1

Weichai Medium Speed Unit Series 60Hz Marine Diesel Generator for Ship Power 200kVA-1500kVA Silent Diesel Generator

Description:

Marine engines of various horsepower can be equipped with generators, gearboxes, water pumps, fire pumps, etc., can be customized.

Industry-Specific Attributes:

Marine Generator Weichai Medium Speed ​​Generator Series Propulsion Engines 10-1800kw Ship Diesel Generators for Vessel/Boat/Emergency

    * Send us your question, we will respond in the next 24 Hours

    Description

    Weichai series Model Unit common power/kW Continuous power of unit/kW Diesel engine model Engine Brand Startup method Speed ​​mode Emission stage Overall dimensions/mm Net weight/kg
    WHM6160 CCFJ200J-* 200 200 WHM6160D258-1 CSIC
    Kangfu    		 Electric start
    Gas start    		 electronic IMOⅡ 3388*1227*1977 4892
    CCFJ250J-* 250 250 WHM6160D300-1 IMOⅡ 3445*1227*1977 5010
    CCFJ300J-* 300 300 WHM6160D330-1 IMOⅡ 3540*1227*1977 5126
    CCFJ300J-* 300 300 WHM6160D350-5 IMOⅡ 3233*1312*1984 5132
    CCFJ350J-* 350 350 WHM6160D426-5 IMOⅡ 3466*1236*2001 5363
    CCFJ400J-* 400 350 WHM6160D456-5 IMOⅡ 3466*1236*2001 5363
    X6170 CCFJ250J-* 250 250 X6170ZCD280-1 CSIC
    Kangfu    		 Electric start
    Gas start    		 Electronic control: China’s first
    Mechanical/electronic:IMOⅡ    		 3288*1255*1977 5152
    CCFJ300J-* 300 300 X6170ZCD330-1 3241*1255*1977 5307
    CCFJ350J-* 350 350 X6170ZCD390-4 3400*1236*2001 5230
    CCFJ400J-* 400 400 X6170ZCD440-4 3466*1236*2001 5282
    CCFJ450J-* 450 400 X6170ZCD500-5 3728*1406*2004 6513
    CCFJ500J-* 500 400 X6170ZCD556-5 3728*1406*2004 6513
    CCFJ500J-* 500 450 X6170ZCD601-5 3728*1406*2004 6513
    8170 CCFJ400J-* 400 400 8170ZCD441-1 CSIC
    Kangfu    		 Electric start
    Gas start    		 electronic IMOⅡ 4424*1493*2277 6251
    8170 CCFJ500J-* 500 500 8170ZCD600-5 IMOⅡ 4418*1406*2004 7263
    8170 CCFJ400J-* 400 400 8170ZCD441-1* CSIC
    Kangfu    		 Electric start Electronic Control IMOⅡ/China I 4424*1493*2277 6251
    8170 CCFJ450J-* 450 450 8170ZCD490-1* IMOⅡ/China I 4418*1406*2004 7263
    8170 CCFJ500J-* 500 500 8170ZCD600-5* IMOⅡ/China I 4418*1406*2004 7263
    8170 CCFJ400J-* 400 400 8170ZCD441-1* CSIC
    Kangfu    		 Electric start Electronic Control IMOⅡ/China I 4424*1493*2277 6251
    8170
    8170 CCFJ450J-* 450 450 8170ZCD490-1* IMOⅡ/China I 4418*1406*2004 7263
    8170 CCFJ500J-* 500 500 8170ZCD600-5* IMOⅡ/China I 4418*1406*2004 7263
    6WH17* CCFJ450J-* 450 450 6WH17CD539-1 CSIC Electric start Electronic Control IMOⅡ/China II 4435*1550*1715 8150
    CCFJ500J-* 500 500 6WH17CD638-2 IMOⅡ/China II 4435*1550*1715 8150
    CCFJ550J-* 550 500 6WH17CD660-5 IMOⅡ/China II 4435*1550*1715 8150
    CCFJ600J-* 600 500 6WH17CD809-5 IMOⅡ/China II 4435*1550*1715 8150
    12WH17* CCFJ800J-* 800 800 12WH17CD990-1 CSIC Electric start Electronic Control IMOⅡ/China II 5315*1600*1782 12868
    CCFJ1000J-* 1000 900 12WH17CD1210-2 IMOⅡ/China II 5315*1600*1782 12868
    CCFJ1000J-* 1000 1000 12WH17CD1265-5 IMOⅡ/China II 5315*1600*1782 12868
    CCFJ1200J-* 1200 1200 12WH17CD1485-5 IMOⅡ/China II 5315*1600*1782 12868
    CCFJ1500J-* 1500 1300 12WH17CD1782-5 IMOⅡ/China II 5315*1600*1782 12868
    CW200 CCFJ450J-* – 450 CW6200ZD-39 CSIC Gas start Electronic Control IMOⅡ/China I 4550*1800*2450 11500
    CCFJ500J-* – 500 CW6200ZD IMOⅡ/China I 4550*1800*2450 11500
    CCFJ600J-* – 600 XCW6200ZD IMOⅡ/China I 4600*1800*2450 12000
    CCFJ700J-* – 700 XCW6200ZD-10 IMOⅡ/China I 4600*1800*2450 12500
    CCFJ800J-* – 800 XCW8200ZD-1 IMOⅡ/China I 5300*2000*2500 14000
    CCFJ900J-* – 900 XCW8200ZD-10 IMOⅡ/China I 5300*2000*2500 14000
    CCFJ1000J-* – 1000 XCW8200ZD-2 IMOⅡ/China I 5300*2000*2500 14000
    CCFJ1200J-* – 1200 XCW12V200ZD IMOⅡ/China I 5400*1900*3000 20000
    CCFJ1500J-* – 1500 CW16V200ZD IMOⅡ/China I 6500*1900*3000 25000
